BF7.00''-series

Product description

Return to product list

No.

Specifications


Part Number

Resolution Pixel

Touch Panel

Outline Size(mm)

Active Area(mm)

Viewing Angle

Drive IC

Interface

Drawing/Datasheet

01

BF7030-01

1024*600

NO

164.90(W) x 100.00(V) x 3.10(T)

153.84(H) x 85.63(V)

IPS

EK79007AD+EK73217

MIPI

02

BF7030-02

1024*600

NO

164.96(W) x 100.06(V) x 3.49(T)

154.22(H) x 85.92(V)

IPS

EK79007AD3+EK73217BCGA

MIPI

03

BF7040-01

800*480

NO

164.90(W) x 100.00(V) x 3.50(T)

153.84(H) x 85.63(V)

12 o'clock

EK9716BD4 + EK73002AB2

RGB

04

BF7040-01R

800*480

Resistive Touch Panel

164.90(W) x 100.00(V) x 4.90(T)

153.84(H) x 85.63(V)

12 o'clock

EK9716BD4 + EK73002AB2

RGB

05

BF7040-02

800*480

NO

165.00(W) x 104.09(V) x 5.30(T)

152.40(H) x 91.44(V)

12 o'clock

HX8262 + HX8678

RGB

06

BF7040-03

800*480

NO

164.90(H) x 100.00(V) x 3.30(T)

154.08(H) x 85.92(V)

6 o'clock

EK9713CA+EK73002

RGB

07

BF7040-04

1024*600

NO

164.90(H) x 100.00(V) x 3.50(T)

153.60(H) x 90.00(V)

IPS

JD9165A

RGB

08

BF7050-01

800*480

NO

164.9(H) x 100.00(V) x 3.50(T)

153.84(H) x 85.63(V)

12 o'clock

EK9716BD4 & EK73002AB2

RGB

09

BF7050-01R

800*480

Resistive Touch Panel

164.9(H) x 100.00(V) x 5.00(T)

153.84(H) x 85.63(V)

12 o'clock

EK9716BD4 & EK73002AB2

RGB

10

BF7050-02 (300CD/M²)

1024*600

NO

164.90(W) x 100.00(V) x 2.80(T)

154.08(H) x 85.92(V)

IPS

JD79001DCGB + JD73215BCGA

RGB

11

BF7050-02C (300CD/M²)

1024*600

Capacitive Touch Panel

164.90(W) x 100.00(V) x 4.25(T)

154.08(H) x 85.92(V)

IPS

JD79001DCGB + JD73215BCGA

RGB

12

BF7050-03 (850CD/M²)

1024*600

NO

164.90(W) x 100.00(V) x 2.80(T)

154.08(H) x 85.92(V)

IPS

JD79001DCGB + JD73215BCGA

RGB

13

BF7050-03C (850CD/M²)

1024*600

Capacitive Touch Panel

164.90(W) x 100.00(V) x 4.25(T)

154.08(H) x 85.92(V)

IPS

JD79001DCGB + JD73215BCGA

RGB

14

BF7050-04 (1000CD/M²)

1024*600

NO

164.90(W) x 100.00(V) x 2.80(T)

154.08(H) x 85.92(V)

IPS

JD79001DCGB + JD73215BCGA

RGB
