Home > PRODUCTS > TFT Display > BF10.10''-series
COB LCD COG LCD TFT Display OLED Display LCD Glass Backlight

BF10.10''-series

Product description
Return to product list
No.
Specifications
Part Number
Resolution Pixel
Touch Panel
Outline Size(mm)
Active Area(mm)
Viewing Angle
Drive IC
Interface
Drawing/Datasheet
01
BF10131-01
800*1280
NO
143.00(W) x 228.60(H) x 2.60(T)
135.36(H) x 215.58(V)
IPS
ILI9881C
MIPI
Icon
02
BF10140-01
1280*800
NO
229.80(W) x 149.00(H) x 5.68(T)
216.96(H) x 135.60(V)
IPS
ILI2511(COF)
LVDS / MIPI
Icon
03
BF10140-02
1280*800
NO
229.46(W) x 149.10(H) x 2.65(T)
216.96(H) x 135.60(V)
IPS
LVDS
Icon
04
BF10140-03
440*1920
NO
64.98(W) x 266.39(H) x 7.25(T)
57.95(H) x 252.86(V)
IPS
ILI9881C
MIPI
Icon
05
BF10150-01
1024*600
NO
235(W)x143(H)x5.0(T)
222.72(H)x125.28(V)
IPS
HX8282A11+HX8696
RGB
Icon
